RAPTOR 2.75m rack upright
The RAPTOR 2.75m Rack Upright is the taller vertical option in the RAPTOR system. At 2.75 metres, it provides additional overhead clearance for climbing ropes, gymnastic rings, high pull-up bars, and rope anchors — without needing separate extenders.
Laser-cut from 75 × 75 × 3 mm steel with numbered holes at 80 mm centre spacing, the upright offers the same precision and build quality as its 2.4m counterpart. The electrostatic powder-coated finish ensures long-term scratch resistance under heavy daily use.
Two uprights pack per carton for efficient logistics. A foundational component for performance centres, large commercial gyms, and competition training facilities with ceiling heights to match.
| Product Length mm | 200 |
| Product Width mm | 130 |
| Product Height mm | 2750 |
| Product Weight KG | 19 |
| Box Length mm | 2795 |
| Box Width mm | 245 |
| Box Height mm | 170 |
| Box Weight KG | 41 |
| No of Boxes per Unit | 2Pcs Into One Carton |
| Packaging Type | Carton |
| Material (+finish) | Powder Painting Steel |
| Color 1 (RAL/Pantone) | Black |
| Suitable for outdoor installation/storage? | No |
| Assembly Required | Yes |
| Stackable (Y/N) | Yes |
| USP / PRODUCT | The Steel Is Treated With An Electrostatic Powder Coating, Providing A Strong Adhesion And Exceptional Durability, Reliable Structure And Made To Last. Nice Welding And Precise Cutting On Measurement |
| Upright Height mm | Stride Raptor Series Only Contain Two Different Heights Of Uprigths: 2.40M Uprights And 2.75M Uprights The Squat Spacing Is 1100mm And The Interval Spacing Is 1800mm |
| Steel Gauge | 34 Gauge 75*75mm Tubes And 3mm Thick Steel |
| Hole Spacing mm | 8Cm Center Hole Spacing |
| Hole Size | 17mm Hole Diameter M16 Screws |
| Material | Steel |
| Assembly Material Included | Only Included The Hardware Like Screws The Tools Like The Allen Key Or The Wrench Are Not Included |
| Max Weight | Ball Rail 1.10M:Loading Capacity 400KG,The Weights Need To Be Evenly Spaced Out. Ball Rail 1.80M:Loading Capacity 250KG,The Weights Need To Be Evenly Spaced Out. Dumbbell Shelf 1.10M:Loading Capacity 300KG,The Weights Need To Be Evenly Spaced Out. Dumbbell Shelf 1.80M:Loading Capacity 350KG,The Weights Need To Be Evenly Spaced Out. Flat Shelf 1.10M:Loading Capacity 300KG,The Weights Need To Be Evenly Spaced Out. Flat Shelf 1.80M：Loading Capacity 350KG,The Weights Need To Be Evenly Spaced Out. Plate Rack 1.10M: Loading Capacity 300KG,The Weights Need To Be Evenly Spaced Out. Plate Rack 1.80M: Loading Capacity 400KG,The Weights Need To Be Evenly Spaced Out. |
| Warranty Period | 1 Year |
